KENWOOD TS-50S

Kenwood TS-50S is a compact HF transceiver



The Kenwood TS-50S is a compact HF transceiver designed for amateur radio operators seeking high performance in a small, rugged form factor. Covering the entire HF spectrum from 1.8 to 30 MHz, including the WARC bands, the TS-50S delivers up to 100 watts of output power on all modes — SSB, CW, and AM — making it well-suited for both base station and mobile operation.



General Specification

Details

Type

HF Transceiver

Frequency Coverage (TX)

1.8 – 29.7 MHz (160–10 meters, incl. WARC)

Frequency Coverage (RX)

500 kHz – 30 MHz

Operating Modes

USB, LSB, CW, AM

IF Frequencies

8.83 MHz (1st), 455 kHz (2nd)

Frequency Stability

±10 ppm (0°C to +50°C)

Antenna Impedance

50 ohms, unbalanced

Power Supply Voltage

13.8 VDC ±15% (negative ground)

Current Drain

RX: 1.5 A max, TX: 20 A max

Dimensions (W × H × D)

179 × 60 × 255 mm (7" × 2.4" × 10")

Weight

Approx. 2.7 kg (6 lbs)



Transmitter Specification

Details

Output Power

10 – 100 watts adjustable (5W min in AM)

Modulation

SSB: Balanced, AM: Low-level

Spurious Emissions

>50 dB below carrier

SSB Carrier Suppression

>40 dB

Microphone Impedance

600 ohms

ALC Range

–10 to +10 dB

Harmonics Suppression

>40 dB

Duty Cycle

100% (CW), SSB/AM as per mode



Reciever Specification

Details

Sensitivity (10 dB S+N/N)

SSB/CW: <0.2 μV, AM: <2.0 μV

Selectivity (SSB)

2.4 kHz (–6 dB), ≥4.0 kHz (–60 dB)

Selectivity (CW)

500 Hz or optional narrow filter

Selectivity (AM)

6.0 kHz (–6 dB), ≥12 kHz (–50 dB)

IF Notch Filter

Yes

RF Gain Control

Yes (Manual & AGC)

Audio Output Power

1.5 W into 8 ohms

RIT (Receiver Incremental Tuning)

±1.0 kHz



Features

  • Built-in Automatic Antenna Tuner Control (for AT-50)

  • Direct Digital Synthesizer (DDS) technology

  • 100 Memory Channels

  • Automatic Gain Control (AGC): Fast, Slow, Off

  • Noise Blanker

  • IF Shift

  • RIT/XIT (Receiver/Transmitter Incremental Tuning)

  • VOX (Voice Operated Transmit)

  • Multi-function LCD Display with Backlight

  • Keypad Entry and VFO Tuning

  • CW Semi/Full Break-in

  • Optional CW Filter (YF-114C) and SSB Narrow Filter (YF-114SN)



Rear Panel Connectors

  • Antenna (SO-239)

  • Power Input (13.8V DC, 6-pin Molex)

  • External Speaker (3.5 mm mono)

  • AT-50 Interface (8-pin DIN)

  • CW Key input (3.5 mm)

  • ACC1 (6-pin mini DIN) – for PC interface or remote control

  • ACC2 (13-pin DIN) – for external accessories



Repairs, maintenance and related projects

Kenwood TS-50 Lithium memory battery replacement.

TS-50 Memory Battery

13 August 2022

Kenwood TS-50 radio - laptop interface with internal USB soundcard and VOX circuit.

SOUND CARD INTERFACE WITH VOX

12 April 2025
